Parts: Tunnel Aft

Tunnel Fore

Tunnel Middle

Tunnel End

Cut out the parts listed above and score along indicated lines.

Fold/assemble into the shapes seen below.

OPTIONAL ASSEMBLY:

Parts Tunnel Aft and Tunnel Fore may be assembled as is, or for a more detailed look, remove the white sections between the grey girder texture.

Color the opposite side of the pieces black or dark grey prior to assembly.

It is recommended to use CA (cryanoacetate or SuperGlue) to strengthen the open gridwork should this option be used.

Attach Tunnel End to the upper side of part BL5, centering as shown below. Note that the rear edge of Tunnel End is flush with the rear edge of part BL5.

Attach part Tunnel Fore to the rear of Tunnel End as shown below, carefully aligning all edges:

Attach part Tunnel Middle to the rear of Tunnel Fore as shown below. Note that part Tunnel Middle is slightly larger than Tunnel Fore. This is intentional. Position the piece so that there is a small overlap as shown below:

Attach Tunnel Aft to the rear of Tunnel Middle, aligning carefully to maintain the small overlap as shown below:
