User Manual
Model: WKL-BEAM008A
 Wecan Technology and Lighting Co., Ltd
www.wecanlight.com
Ⅰ. Technical reference
Voltage: AC 110-240v, 50/60Hz
Power consumption: 100w
Lamp: CREE 12w × 8PCS LED (RGBW 4into 1)
Channel: 10/38 CH
Control: DMX, Master slave mode, auto mode, sound mode
Movement range: 180°
Carton size: 1250×130×200mm
G.W.: 8kg
Display: Digit

Display board schematic diagram
Display1:
| NO.
| Display
| Function
| |
| A001
| Choose DMX 10CH address
| |
| D001
| Choose DMX 38 CH address
| |
| CC00
| RGBW Beating changes（01—99）
Press B、C change speed
| |
| CP00
| RGBW Gradual change（01—99）
Press B、C change speed
| |
| DE00
| Pulse change （01—99）
Press B、C change speed
| |
| FF00
| track changes（01—99）
Press B、C change speed
| |
| BEB1
| track changes 1 by Sound
| |
| BEB2
| track changes 2 by Sound
| Display2: when display A001, press A for a long time,so can into Setting Surface (press D can exit )
|
| R 1…4
| RED Error correction, Press B、C untill red on
| |
| G 1…4
| GREEN Error correction, Press B、C untill green on
| |
| B 1…4
| BULE Error correction, Press B、C untill bule on
| |
| O 1…4
| WHITE Error correction, Press B、C untill white on
| |
| R200（020—255）
| RED current adjustment，press B、C adjust it
| |
| G200（020—255）
| GREEN current adjustment，press B、C adjust it
| |
| B200（020—255）
| BULE current adjustment，press B、C adjust it
| |
| O200（020---255）
| WHITE current adjustment，press B、C adjust it
| |
| t o …t f
| Motor Forward and reverse adjustment，press B、C adjust it（default t o）
|
Channel list 38CH
| CH
| Function
| Value
| Description
| |
| Motor moving
| 0-255
|
| |
| Motor speed
| 0-255
|
| |
| Dimmer
| 0-255
| RGBW Dimmer
| |
| Strobe
| 0-255
| RGBW Strobe
| |
| Macro
| 0-20
| DMX 38CH MODE
| | 21-70
| Beating changes
| | 71-120
| Gradual change
| | 121-170
| Pulse change
| | 171-220
| track changes
| | 221-240
| Sound 1
| | 241-255
| Sound 2
| |
| Macro speed
| 0-255
| Slow-fast
| |
| Dimmer R1
| 0-255
| R1 From dark to light
| |
| Dimmer G1
| 0-255
| G1 From dark to light
| |
| Dimmer B1
| 0-255
| B1 From dark to light
| |
| Dimmer W1
| 0-255
| W1 From dark to light
| |
| Dimmer R2
| 0-255
| R2 From dark to light
| |
| Dimmer G2
| 0-255
| G2 From dark to light
| |
| Dimmer B2
| 0-255
| B2 From dark to light
| |
| Dimmer W2
| 0-255
| W2 From dark to light
| |
| Dimmer R3
| 0-255
| R3 From dark to light
| |
| Dimmer G3
| 0-255
| G3 From dark to light
| |
| Dimmer B3
| 0-255
| B3 From dark to light
| |
| Dimmer W3
| 0-255
| W3 From dark to light
| |
| Dimmer R4
| 0-255
| R4 From dark to light
| |
| Dimmer G4
| 0-255
| G4 From dark to light
| |
| Dimmer B4
| 0-255
| B4 From dark to light
| |
| Dimmer W4
| 0-255
| W4 From dark to light
| |
| Dimmer R5
| 0-255
| R5 From dark to light
| |
| Dimmer G5
| 0-255
| G5 From dark to light
| |
| Dimmer B5
| 0-255
| B5 From dark to light
| |
| Dimmer W5
| 0-255
| W5 From dark to light
| |
| Dimmer R6
| 0-255
| R6 From dark to light
| |
| Dimmer G6
| 0-255
| G6 From dark to light
| |
| Dimmer B6
| 0-255
| B6 From dark to light
| |
| Dimmer W6
| 0-255
| W6 From dark to light
| |
| Dimmer R7
| 0-255
| R7 From dark to light
| |
| Dimmer G7
| 0-255
| G7 From dark to light
| |
| Dimmer B7
| 0-255
| B7 From dark to light
| |
| Dimmer W7
| 0-255
| W7 From dark to light
| |
| Dimmer R8
| 0-255
| R8 From dark to light
| |
| Dimmer G8
| 0-255
| G8 From dark to light
| |
| Dimmer B8
| 0-255
| B8 From dark to light
| |
| Dimmer W8
| 0-255
| W8 From dark to light
|
Channel list 10CH
| CH
| Function
| Value
| Description
| |
| Motor moving
| 0-255
|
| |
| Motor speed
| 0-255
|
| |
| Dimmer
| 0-255
| RGBW Dimmer
| |
| Strobe
| 0-255
| RGBW Strobe
| |
| Macro
| 0-20
| DMX 10CH MODE
| | 21-70
| Beating changes
| | 71-120
| Gradual change
| | 121-170
| Pulse change
| | 171-220
| track changes
| | 221-240
| Sound 1
| | 241-255
| Sound 2
| |
| Macro speed
| 0-255
| Slow-fast
| |
| Dimmer R
| 0-255
| R From dark to light
| |
| Dimmer G
| 0-255
| G From dark to light
| |
| Dimmer B
| 0-255
| B From dark to light
| |
| Dimmer W
| 0-255
| W From dark to light
|
